Chosfox x masro | Fox65 QMK/VIA Mechanical Keyboard Kit

Pre-sale！！！

delivery time: October 10th

: Orders from Japan want to choose the single-mode non-Bluetooth version, please contact customer service.

New Chosfox Mechanical Keyboard FOX65
Co-designed by Chosfox and Masro

The Fox65 is a keyboard that combines sophisticated beauty and functionality with its streamlined, rounded design. This design fits naturally in the user's hand and provides comfort even when used for long periods of time.

Design Features
The smooth, curved design is visually beautiful and gentle on the hand.
The soft edges and corner-free design combine ease of use and comfort. The interior is uneven, effectively scattering the sound of typing and achieving a milder keystroke sound.
The body is made of high-quality aluminum material, which enhances the beauty of the design while ensuring durability.
The compact 65% layout design allows you to use the space on your desk more widely.

The Fox65 design pursues beauty and ease of use, providing users with an outstanding typing experience.

Basic:

• Product name: Fox65

• Keyboard type: mechanical keyboard

• Keyboard material: aluminum alloy shell (pure CNC)

• Keyboard Structure: Gasket/Top Dual-structure

• Support: QMK/VIA (Windows / macOS / ios / Android),JION

• QMK/VIA Supported for all 3 connection modes

• 2.4G Wireless/Wired/BT 5.1 Connection

• 1.2mm PCB, hot-swap supported
  South-facing RGB， PogoPIN Match

• Shell process: electrophoresis / anodized

• Interchangeable right-side Pusher/Keypad

• PC plate: FR4, Pom，PC

• Supported switches: MX-like 3-Pin/5-Pin

• Counterweight: stainless steel, brass, red copper

Pusher/Keypad Version

*Pusher version：Volume adjustment is different between Windows and Apple system

Features:

• 65% keyboard 64/67 keys

• PCB satellite axis (Supports 6.25u and space triple split, left shift split, ANSI and ISO carriage return switching, such functions are realized on the steel plate satellite axis)

• Dimensions: 322*114mm

• Typing angle: 7°

• Front height: 19mm

• Back height: 30mm

• Colors:
   Pearl White/Polar Blue (Electrophoresis)；

           Dark night black/snow green purple/ starlight silver (anodized)

• Battery: 3.7V/2000mAh  5V=1A

• Kit only with PCB and Plates, no switches or keycaps.


Package includes:

CNC-machined aluminum case
Rotary encoder
Gasket Kit
Poron case foam/switch pad
Non-flex cut PCB
Flex-cut PC Plate
Chosfox JWK screw-in stabilizers
USB-C cable
Chosfox Custom Carry Case
2.4GHz receiver
Hex Screw Driver
2-in-1 Switch Keycap Puller
All screws required for assembly
